okay welcome to part four of the albot
0:07
project where we're going to be
0:09
upgrading the power supply to our albot
0:13
prototype circuit as you can see here we
0:16
have the Prototype circuit set up on the
0:21
ultimate DIY 3220 point breadboard or 2D
0:26
I have 2D right here this was a previous
0:30
project build that uh you can try out
0:33
yourself if you'd like to if not uh I
0:36
give instruction on how to set up this
0:39
prototype circuit for the albot in
0:41
complete detail on the blog post project
0:45
series I'll leave the
0:47
description uh or the link to the
0:51
below but like I said for this part part
0:54
four we're going to be upgrading the
0:56
power supply and the reason why we want
0:59
to do that is because in part five the
1:04
next part of this uh build series we're
1:07
going to be adding a DC motor as you can
1:10
see I already have it set up here and a
1:14
couple of solenoids so the 2D here has
1:17
an onboard 9vt battery power supply or
1:21
if you're using just a generic uh
1:24
breadboard we've been using a 9volt
1:27
battery supply to provide Power
1:30
for both the Arduino and the MP3 player
1:34
that we installed in part two of the
1:37
project and the uh LEDs that we
1:41
installed on our prototype circuit in
1:45
project so later we're going to want to
1:48
add the DC motor and the
1:50
solenoids but having a single 9volt
1:53
battery power supply isn't going to
1:56
really quite cut it to power everything
2:00
have currently and what we want to add
2:03
on in the future or in the future builds
2:06
so in order to provide the power that we
2:08
will need especially for the DC motor
2:11
and the solenoids we're going to need to
2:13
add a another source or another way to
2:19
provide Power for everything and the way
2:22
that I'm going to be doing it for part
2:25
four here of this project uh build
2:29
series for the albot project I'm going
2:32
to add a secondary power
2:35
supply and what I'm going to use is this
2:39
uh battery pack that holds six ablea
2:43
batteries this one already has the
2:46
batteries uh installed in it and this
2:57
convenient 9volt battery snap connector
3:01
so the six batteries makes up 9 volts
3:04
this particular battery pack has the 9vt
3:06
battery snap connector which in the
3:09
future when installing this inside the
3:12
body of the uh owl figure that we're
3:17
using if you just give me a second I'll
3:20
that so in the future we're going to
3:23
stick everything inside this ow figure
3:26
it's kind of too big to put them all
3:28
into the camera sh sh right now but we
3:32
want to have something that would be
3:35
easily installed inside that Al figure
3:39
and something like this would be fine
3:41
and uh in order to change the batteries
3:44
out in the future it's much easier to
3:47
have something like this or where you
3:48
can just snap that off take this out
3:51
change your batteries and then snap it
3:54
back in and of course these wires will
3:57
be attached to the rest of the circuit
4:03
albot so before I jump into
4:07
this as that was mentioned on
4:11
the blog post for part four of the albot
4:16
project we needed to add a couple of
4:19
jumper wires uh in order to create a
4:23
common ground for the entire uh
4:25
prototype circuit so here we have the
4:31
9volt battery power supply and in part
4:34
one I showed you uh at least from 2D and
4:39
for a generic breadboard if you're using
4:41
that that we connected the plus and
4:46
minus supply of the 9volt battery to the
4:51
here and this is the negative Supply
4:56
here you can see that there's a blue
4:57
jumper wire to connect the rest of this
5:00
uh these points here on this rail here
5:04
I've added a white jumper wire that goes
5:08
from the negative supply of the main
5:11
power rail from the 9volt battery power
5:16
here and this is the negative Supply or
5:20
I've created the negative Supply on this
5:23
rail along here you can kind of see that
5:26
black jumper wire that connects the rest
5:29
of this negative Supply here and all the
5:32
the uh negative uh points that we'll
5:35
make for the other circuitry that will
5:37
add later that circuitry is actually
5:40
hidden underneath this pier sensor right
5:42
now so you'll get to see that in part
5:45
five uh of this build and I've also
5:49
added this other white jumper wire right
5:52
here and it's also connected to the same
5:57
negative uh rail here and
6:00
it's continued throughout through this
6:03
jumper wire to this other negative rail
6:06
on this side where we added the negative
6:11
for both the Arduino and the MP3 player
6:15
and also the uh LEDs so this negative
6:19
Supply rail here that we added in I
6:22
believe either part two I think in part
6:24
two of the build and then this new uh
6:29
connected negative Supply rail that
6:31
we're doing in this part of the project
6:35
and the main negative uh side of or the
6:38
main rail for the negative side from the
6:41
9volt battery power supply is all
6:43
connected so we've created a common
6:47
throughout so just going back over it
6:50
once again this is this black wire here
6:53
is representative of my negative Supply
6:56
from the onboard 9volt battery power
7:02
negative Supply is continued to this
7:05
main power rail here and continues
7:09
through this blue jumper wire all the
7:12
way down to this white jumper wire and
7:15
continued on to this white jumper wire
7:17
jumper wire so both of these white
7:20
jumper wires go to either
7:23
side of this breadboard here this
7:27
negative rail here and this negative
7:29
rail on this side and these negative
7:32
rails are connected all
7:37
down so all of these are connected to
7:40
create a common ground and we need a
7:42
common ground for the uh prototype
7:45
circuit to work properly and all that's
7:47
explained in uh the blog post again I'll
7:51
leave that in the description below for
7:53
this part four of the albot project
7:56
build Series so that was one of the
7:58
first things that we needed to set up
8:00
for this part before we add our
8:02
secondary power supply which again I'm
8:05
using a sixpack of ablea batteries and
8:09
all I will need to do next is that I'll
8:15
the positive to I'm connecting it to
8:18
this side rail and I'm connecting the
8:21
negative to the negative rail for this
8:24
new power supply rail on this side of
8:29
this uh breadboard that we're using on
8:32
this end of 2D so to recap for all that
8:36
we're doing for part four of this build
8:40
is that we are creating a common ground
8:44
so again this comes from the negative
8:47
supply of the 9volt battery it's
8:52
main uh Power rail here on the negative
8:55
rail there's a jumper wire to connect
9:02
here and also this jumper wire over here
9:05
to connect this uh negative rail that we
9:08
set up in the previous parts of the
9:10
build so that all the negatives are
9:13
connected to together to create a common
9:17
ground and then next all we needed to do
9:20
was grab our secondary power supply in
9:23
this case I'm using a six doublea
9:28
battery pack and connecting its positive
9:32
to the positive rail to this new uh
9:35
Power rail that we're creating here and
9:38
I'm connecting the negative line which
9:41
is this black wire from the battery pack
9:44
to the negative rail here so this new
9:47
rail here that we're creating for the
9:50
new uh 9vt battery power supply with the
9:54
six AA batteries is going to create a a
9:57
better more stable uh power supply for
10:03
the solenoids and the DC motor that will
10:06
add in the next part of this build for
10:09
part five so we have our 9vt battery
10:13
power supply that we set up in part one
10:17
of the project we have our secondary
10:20
9volt battery power supply that includes
10:23
that uh is made up of six AA batteries
10:29
here and this is the rail that we're
10:31
going to use for the DC motor and the
10:35
two solenoids later in the
10:38
project and we still have our this is
10:42
5vt power supply rail that comes
10:45
directly from the 5vt supply of the
10:48
Arduino and again the Arduino we hooked
10:51
up to the 9vt battery power supply
10:55
here so that's all we're doing for part
10:57
four I just wanted to create this quick
11:00
video in order to kind of explain
11:03
verbally what we're doing you can get uh
11:06
the complete instructions for this part
11:08
of the build and for the previous parts
11:11
of the build uh down in the links down
11:14
in or in the links down in the
11:16
description below I'll leave that for
11:17
you so it's easier for you to find where
11:19
all that is so next up we're going to be
11:24
adding this DC motor and the two
11:27
solenoids and uh then we we move on from
11:30
there to work our way into
11:32
completing the albot project and
11:35
hopefully sometime soon we can add all
11:38
of this stuff inside this guy here so I
11:42
want to thank you for watching and uh
11:44
stay tuned for part five of the albot
11:47
project where again we'll be adding the
11:50
mechanical movements for our albot
11:54
prototype circuit the DC motor and the
11:57
two solenoids so I'll see you next time
12:00
take care and remember to keep at it and
